Assembler Window
The Assembler plugin allows you to view and modify the *.asm file generated by the compiler. Using the Assembler window to modify the generated *.asm file is not really recommended, unless you have some experience using assembler.
Assembler Menu Bar
File Menu New - Creates a new document. A header is automatically generated, showing information such as author, copyright and date.
• Open - Displays a open dialog box, enabling you to load a document into the Assembler
plugin. If the document is already open, then the document is made the active editor page.
• Save - Saves a document to disk. This button is normally disabled unless the document
has been changed. If the document is 'untitled', a save as dialog is invoked. A save as dialog is also invoked if the document you are trying to save is marked as read only.
• Save As - Displays a save as dialog, enabling you to name and save a document to
disk.
| • | Close - Closes the currently active document. |
| • | Close All - Closes all editor documents and then creates a new editor document. |
| • | Reopen - Displays a list of Most Recently Used (MRU) documents. |
| • | Print Setup - Displays a print setup dialog. |
| • | Print - Prints the currently active editor page. |
| • | Exit - Enables you to exit the Assembler plugin. |
Edit Menu
| • | Undo - Cancels any changes made to the currently active document page. |
| • | Redo - Reverse an undo command. |
| • | Cut - Cuts any selected text from the active document page and places it into the clip- |
board.
• Copy - Copies any selected text from the active document page and places it into the
clipboard.
• Paste - Paste the contents of the clipboard into the active document page. This option is
disabled if the clipboard does not contain any suitable text.
| • | Delete - Deletes any selected text. This option is disabled if no text has been selected. |
| • | Select All - Selects the entire text in the active document page. |
| • | Find - Displays a find dialog. |
| • | Replace - Displays a find and replace dialog. |
| • | Find Next - Automatically searches for the next occurrence of a word. If no search word |
has been selected, then the word at the current cursor position is used. You can also select a whole phrase to be used as a search term. If the editor is still unable to identify a search word, a find dialog is displayed.
View Menu
| • | Options - Displays the application editor options dialog. |
| • | Toolbars - Display or hide the main and assemble and program toolbars. You can also |
toggle the toolbar icon size.
Help Menu Help Topics - Displays the IDE help file.
About - Display about dialog, giving the Assembler plugin version number.
